1C20B

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name1C20B
Typerectifier
Applicationscan retreating pulses rectification
Cathode typeoxide, direct heating
Envelopeglass, miniature
Mass, g5
Filament voltage, V1
Filament current, A0,22-0,28
Anode voltage, V50
Max.reverse anode voltage, kV10
Anode current, A0,0035
