NameUV-260
Application fieldUHF output amplification
Cathode typeOxide, indirect heating
Output typecoaxial
Envelopeglass
Mass3,5kg
Cooling methodforced water
Frequency range1002-972Mhz
Output power50W
Gain27dB
Filament voltage, V12,6
Filament current, A0,5-0,9
First anode voltage, V1900-2200
Slow-wave circuit voltage, V1900-2200
Control electrode voltage, V2-100
Collector voltage, V1400-1600
External loading agreement coefficient1,7
