NameUV-42
Application fieldHF power amplification
Cathode typeOxide, indirect heating
Output typecoaxial
Envelopeglass with metal envelope
Mass1,8kg
Cooling methodnatural
Frequency range5,6-8,1cm
Gain10-30dB
Filament voltage, V6,3
Filament current, A0,5-0,85
First anode voltage, V150-300
Slow-wave circuit voltage, V1200-1400
Control electrode voltage, V50
Collector voltage, V1400
External loading agreement coefficient3,5
Noise coefficient30-33dB
