NameUV-5
Application fieldUHF amplification in first stage
Cathode typeOxide, indirect heating
Output typewaveguide 10x61mm
Envelopeglass
Mass110g
Cooling methodforced air
Frequency range6,8-8,8cm
Gain18-20dB
Filament voltage, V2,0-3,0
Filament current, A0,5-0,9
First anode voltage, V5-180
Slow-wave circuit voltage, V390-480
Control electrode voltage, V12
Collector voltage, V600
External loading agreement coefficient1,6
Noise coefficient8
