NameUV-50B
Application fieldHF power amplification
Cathode typeOxide, indirect heating
Output typewaveguide 3x17mm
Envelopeglass with permanent magnetic system in metal envelope
Mass1,1kg
Cooling methodnatural
Frequency range2,25-3,0cm
Output power35-300mW
Gain27dB
Filament voltage, V6,3
Filament current, A0,25-0,4
Slow-wave circuit voltage, V1500-2000
Control electrode voltage, V80
Collector voltage, V1500-2000
External loading agreement coefficient4
Noise coefficient31dB
