NameUV-7-1
Application fieldApplication as HF amplifier
Cathode typeOxide, indirect heating
Output typewaveguide 10x61mm
Envelopeglass
Mass150g
Cooling methodforced air
Frequency range7,7-8,8cm
Output power4W
Gain30-35dB
Filament voltage, V6,3
Filament current, A0,6-0,85
Slow-wave circuit voltage, V1100-1400
Control electrode voltage, V50
Collector voltage, V1500
External loading agreement coefficient1,6
Noise coefficient35dB
