NameUV-7
Application fieldUHF amplification in last stage
Cathode typeOxide, indirect heating
Output typewaveguide 10x61mm
Envelopeglass
Mass100g
Cooling methodforced air
Frequency range7,7-8,8cm
Output power3W
Gain26-36dB
Filament voltage, V6,3
Filament current, A0,7-0,85
Slow-wave circuit voltage, V1,1-1,4
Control electrode voltage, V50
Collector voltage, V1500
External loading agreement coefficient1,6
