TGI1-100/8

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameTGI1-100/8
Applicationas commutating device
Envelopemetal-ceramic
Mass275
Frequency, Hz50000
Filament voltage, V6,3
Filament current, A4,4-5,0
Pulse anode current, A100
Average anode current, mA150
Direct and reverse voltage, kV8
Anode current pulse duration, uS0,1-50,0
