G807

Check availability
SG2S pin diagram
Click to see in full size
NameG807
Typebeam tetrode
Application fieldoscillation and power amplification up to 60MHz
Brief applicationoscillation, amplification
Cathode typeoxide, indirect heating
Envelopeglass with base
Mass100g
Cooling methodair
Dimensions146mmx53mm
Output power25W
Maximum operating frequency60MHz
Filament voltage6,3V
Filament current0,81 - 0,99A
Normal anode voltage600V
Maximum anode voltage600V
