GI31R

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameGI31R
Typepulse triode
Application fieldoscillation in VHF and UHF band on anode pulse manipulation
Brief applicationoscillation
Cathode typeoxide, indirect heating
Envelopetitanium-ceramic
Mass18g
Cooling methodforced air
Dimensions34mm x 25,5mm
Output power12W/1,2kW in pulse
Maximum operating frequency7cm
Filament voltage6,3V
Filament current0,9-1,0A
Normal anode voltage0,35kV
Maximum anode voltage2,8kV
Mutual conductance15mA/V
