1N3S

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name1N3S
Typeoutput double triode
Applicationlow frequency power amplification
Cathode typeoxide, direct heating
Envelopeglass
Mass, g40
Socket typersh5-1
Filament voltage, V1,2
Filament current, A0,108-0,132
Anode voltage, V120
Anode current, A0,0025
Anode power, W1
Grid1 voltage, Vminus 5,5
