Name1P24B
TypeHigh-durable penthode
ApplicationOscillation and power amplification in mode B
Cathode typeoxide, direct heating
Envelopeglass, miniature
Mass, g5,5
Socket typeflexible
Filament voltage, V1,2
Filament current, A0,22-0,245
Anode voltage, V150
Anode power, W4
Grid1 voltage, Vminus 14
Grid2 voltage, V125
Reverse grid current, uA0,1
Steepness, mA/V2,1-3,5
Microphonic noise, mV130
