1P32B

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name1P32B
TypeCrashproof penthode
ApplicationHF oscillation
Cathode typeoxide, direct heating
Envelopeglass, miniature
Mass, g5,5
Socket typeflexible
Filament voltage, V1,35
Filament current, A0,195-0,25
Anode voltage, V150
Anode power, W4
Grid1 voltage, Vminus 14
Grid2 voltage, V150
Steepness, mA/V2,0-3,5
Microphonic noise, mV100
