1P4B

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name1P4B
Typeoutput penthode
ApplicationLow frequency power amplification
Cathode typeoxide, direct heating
Envelopeglass, miniature
Mass, g3
Socket typeflexible
Filament voltage, V1,25
Filament current, A0,017-0,023
Anode voltage, V45
Anode power, W0,05
Grid1 voltage, Vminus 2
Grid2 voltage, V45
Steepness, mA/V0,28-0,5
